Unplug the power cord from the power outlet to prevent damage to the devices. Before connecting the power connector, first make sure the power supply is turned off and all devices are properly installed.


The power connector possesses a Gigabyte GA-AM1M-S2P (rev. 1.0) design. Connect the power supply cable to the power connector in the correct orientation. The 12V power connector mainly supplies power to the APU. If the 12V power connector is not connected, the computer will not start.


To meet expansion requirements, it is recommended that a power supply that can withstand high power consumption be used W or greater. If a power supply is used that does not provide the required power, the result can lead to an unstable or unbootable system. Most fan headers possess a foolproof insertion design. When connecting a fan cable, be sure to connect it in the correct orientation the Gigabyte GA-AM1M-S2P (rev. 1.0) connector wire is the ground wire. The speed control function requires the use of a fan with fan speed control design.

Windows 10 Graphics and Motherboard Drivers (Updating) PC Gamer

For optimum heat dissipation, it is recommended that a system fan be installed inside the chassis. Overheating may result in damage to the APU or the system may hang. Do not place a jumper cap on the headers. Note the positive and negative pins before connecting the cables. Connects to the Gigabyte GA-AM1M-S2P (rev. 1.0) switch on the chassis front panel. Connects to the speaker on the chassis front panel. The system reports system startup status by issuing a beep code.

One single short beep will be heard if no problem is detected at system startup. Connects to the Gigabyte GA-AM1M-S2P (rev. 1.0) drive activity LED on the chassis front panel. Connects to the reset switch on the chassis front panel. The front panel design may differ by chassis.

When connecting your chassis B the wire assignments and the pin assignments are front panel module to this header, make sure matched correctly. You may connect your chassis front panel audio module to this header.


Make sure the wire assignments of the module connector match the pin assignments of the motherboard header. Incorrect connection between the module connector and the motherboard header will make the device unable to work or even damage it.

GIGABYTE Announces New AM1 Series Motherboards

For information about connecting the front panel audio module that has different wire Gigabyte GA-AM1M-S2P (rev. 1.0), please contact the chassis manufacturer. For purchasing the optional USB bracket, please contact the local dealer. For purchasing the optional COM port cable, please contact the local dealer. To clear the CMOS values, use a metal object like a screwdriver to touch the two pins for a few seconds.

Replace the battery when the battery Gigabyte GA-AM1M-S2P (rev. 1.0) drops to a low level, or the CMOS values may not be accurate or may be lost. Turn off your computer and unplug the power cord. Socket FS1b supports AMD AM1 Athlon/Sempron-series APU GIGABYTE devices 2 USB ports with GIGABYTE 3x USB power High ESD Protection on. Socket FS1b supports AMD AM1 Athlon/Sempron-series APU GIGABYTE Ultra Durableā„¢ 4 Plus Technology GIGABYTE UEFI DualBIOSā„¢ GIGABYTE On/Off.
